| Model | ZWY-304 | |||||
|---|---|---|---|---|---|---|
| Action Mode | Orbital | |||||
| Speed Range (/min) | 30-300 rounds | |||||
| Speed Variation (/min) | ±1 round | |||||
| Stroke | Ø30 mm | |||||
| Tray Dimensions (mm) | 330×350 | |||||
| Accessory Included | Rubber Bar Tray | |||||
| Timer | 1 minute to 500 hours | |||||
| Maximum Load (kg) | 7.5 | |||||
| Overall Dimensions (mm) (WxDxH) | 400x350x235 | |||||
| Packing Dimensions (mm) (WxDxH) | 490x490x420 | |||||
| Net / Gross Weight (kg) | 25/37 | |||||
| Safety Features | Non-volatile Memory, Power-off Recovery, Timer | |||||
| Power (W) | 50 | |||||
| Electricity | 220-240V 50/60 Hz | |||||
| Approval | CE, ISO | |||||
| Clamp Tray | 50ml | 100ml | 250ml | 500ml | 750ml | 1000ml | 2000ml | 3000ml | 5000ml | Tube Rack S/S | 96 Well Plate |
|---|---|---|---|---|---|---|---|---|---|---|---|
| P6016 | 24 | 17 | 9 | 7 | – | – | – | – | – | 3 | 6 |
| * Glass dimensions may reduce max. capacity | |||||||||||
| Accessories | |
|---|---|
| P6016* | Tray for ZWY-304/ZWF-334, S/S ※ Clamp Tray |
| P6017 | Tray for ZWY-304/ZWF-334, S/S Bar Trayx1, Rubber Barx4, Knobx8 |
| P6018 | Tray for ZWQ-344, Stl S/C# Trayx1, Springx4, Rubber Matx1 |
| P7017 | Universal Spring Tray for ZWY-304/ZWF-334 |
| P8001 | T Clamp, S/S, for 50ml Flask, with Spring Retainer |
| P8002 | T Clamp, S/S, for 100ml Flask, with Spring Retainer |
| P8013 | T Clamp, S/S, for 150ml Flask, with Spring Retainer |
| P8003 | T Clamp, S/S, for 250ml Flask, with Spring Retainer |
| P8014 | T Clamp, S/S, for 300ml Flask, with Spring Retainer |
| P8004 | T Clamp, S/S, for 500ml Flask, with Spring Retainer |
| P8010 | Tube Rack S/S |
| P8011 | Tube Rack ABS Plastic |
| P8012 | Clamp for 96 Well Micro Plate, S/S |
| P8017 | Sticky Mat, 20 x 20cm |
Description
▶ The ZWY-304 provides a smooth, uniform circular motion with an orbit of 30mm. The shaker can be used in incubators and warm rooms if the temperature is not higher than 50°C. 300 rpm
▶ The standard cradle platform can turn the ZWY-304 unit into a very effective mini platform shaker, which allows for different combinations of vessels offering maximum versatility. Alternatively, the tray is interchangeable with a flask clamp tray (ZWF-334a ) or non-slip mat tray (ZWQ-344).
▶ Speed is variable from 30 to 300 rpm, with shaking times set to run from 0 to 500 hours or set for continuous operation. The non-volatile memory restores all settings after a power failure.
 |  |
