UltraGenizer
UltraGenizer
UltraGenizer Ultra High Pressure Homogenizer - Image 3
UltraGenizer Ultra High Pressure Homogenizer - Image 4

UltraGenizer Ultra High Pressure Homogenizer

UltraGenizer-30K, Suitable for Larger Flow Rate Requirements

The UltraGenizer is a ultra-high-pressure homogenizer and cell disruptor suitable for larger flow rate requirements. The maximum pressure of the UltraGenizer is up to 60,000 psi. The UltraGenizer single pump system is smart and simple to operate, including a diamond interaction chamber to disrupt the cell and reduce the particle size. Regarding the sample cooling unit, a 316L stainless heat exchanger can be installed in the system to achieve real-time cooling on the samples. Additionally, the Genizer PLC touch screen creates a simple user interface for operators, including the access to the auto-stop setup (set time, cycles numbers, and pressure). All parts touching with medium are 316L stainless steel, 17-4ph stainless steel, titanium alloy, tungsten carbide, PTFE, UHMWPE or other corrosion resistance materials.

SKU: N/A Categories: , Tags: , , , , , , , , , , , Brand:

This product is currently out of stock and unavailable.

Related products

  • Main features of the UltraGenizer-30K:▶ Pressure: 30,000 psi (2,068 bar)▶ Flow rate: ~12 L / h (water value)▶ Minimum sample volume: ~26 mL

    ▶ Weight: ~110 kg

    ▶ Power requirement: 380V, three phase, 50/60Hz

    ▶ Diamond Interaction Chamber (Electro-Polish and Passivation for pharmaceutical applications)

    ▶Application: Nano emulsions, fat emulsions, liposomes, cell disruption, nano dispersion, deagglomeration

Specifications
Catalog No. UG-20K                       UG-25K                      UG-30K                    UG-40K                           UG-45K                          UG-60K
Flow Rate 35L/hr                          30L/hr                         25L/hr                       20L/hr                              15L/hr                              12L/hr
Min. Sample30mL                            25mL                           25mL                        20mL                                20mL                               15mL
Max. Pressure20,000psi                      25,000psi                    30,000psi                  40,000psi                          45,000psi                         60,000psi
Dimensions(cm)150 × 68 × 48
Weight~200 kg
Max. Temp.70ºC (158ºF)
Power380V
CleaningFlush to clean
ApplicationNano emulsion, fat emulsion, liposome, cell disruption, nano dispersion, de-agglomeration, nanoparticle, graphene
FeaturesDigital display of pressure or pressure gauge

Description

Application of UltraGenizer High Shear Homogenizer:
Nano emulsions
Nano dispersions
Liposomes
Nanoparticles
Graphene
Deagglomeration
Performance of UltraGenizer High Shear Homogenizer:
Energy efficient, 1/2 energy loss of the most homogenizers
Small (integrated design delivers the light weight and small dimensions)
Smart (programming control systems confer diligent functions: controlled inlet volume ± 0.1mL; auto stop with time/volume)
Silent (noiseless performance)
Strong (more than 150 mL/min at 60,000 psi)
CE compliant and RoHS compliant

    Additional information

    Flow Rate

    Reviews

    There are no reviews yet.

    Be the first to review “UltraGenizer Ultra High Pressure Homogenizer”
